Intel® Core® i7-12700F Processor
25M Cache, up to 4.90 GHz

CPU Specifications

· Total Cores 12
· # of Performance-cores 8
· # of Efficient-cores 4
· Total Threads 20
· Max Turbo Frequency 4.90 GHz
· Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 4.90 GHz
· Performance-core Max Turbo Frequency 4.80 GHz
· Efficient-core Max Turbo Frequency 3.60 GHz
· Performance-core Base Frequency 2.10 GHz
· Efficient-core Base Frequency 1.60 GHz
· Cache 25 MB Intel® Smart Cache
· Total L2 Cache 12 MB
· Processor Base Power 65 W
· Maximum Turbo Power 180 W

Processor Graphics

· Processor Graphics ‡ Intel® UHD Graphics 770
· Graphics Base Frequency 300 MHz
· Graphics Max Dynamic Frequency 1.50 GHz
· Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
· Execution Units 32
· Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
· Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
· Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
· DirectX* Support 12
· OpenGL* Support 4.5
· Multi-Format Codec Engines 2
· Intel® Quick Sync Video Yes
· Intel® Clear Video HD Technology Yes
· # of Displays Supported ‡ 4
· Device ID 0x4680
· OpenCL* Support 2.1
